Timing chain

Im from ohio and i was wanting to know if anyone knows what a good price for replacing a timing chain on a 05 ac 500 4x4 would be was qouted 850 parts and labor seems high to me.
dstarr20308 is offline
Sponsored Links
Advertisement

post #2 of 12 Old 02-25-2012, 12:18 PM
Sponsors

ricktherocket's Avatar

Sponsors
Join Date: Jan 2010
Location: Monroe, Indiana 46772
Posts: 3,686
Thanks: 109
Thanked 447 Times in 408 Posts
Garage
Sled: Black Plastic w/ Cat Green Runners
ATV: 2003 AC 400 Auto
Does that include a kiss with the screwing?

That just a little high to replace just a timing chain and a few gaskets!



Please use the link below to view my products, pricing and how to order them.
http://www.arcticchat.com/forum/rtr-custom-fabrication/



http://rtrcustomfab.webs.com/



"ΜΟΛΩΝ ΛΑΒΕ"
ricktherocket is offline
post #3 of 12 Old 02-25-2012, 12:28 PM Thread Starter
Member

Member
Join Date: Apr 2011
Location: ohio
Posts: 37
Thanks: 3
Thanked 0 Times in 0 Posts
Garage
im sure it doesnt i have it at the arctic cat dealer in daytona i called another atv place to compare prices they arent sure what is wrong with it at low idle it makes a clacking noise but it doesnt happen constin it is spiratic
dstarr20308 is offline
Sponsored Links
Advertisement

post #4 of 12 Old 02-28-2012, 07:23 AM
Team ArcticChat

Sanny651's Avatar
Team ArcticChat

Team ArcticChat
Join Date: Sep 2005
Location: MN
Posts: 19,624
Thanks: 31
Thanked 230 Times in 172 Posts
ATV: 2013 550 XT
I could have that whole thing done in 2 hours, soup to nuts. $850.....WAY high man. wow!
Sanny651 is offline
post #5 of 12 Old 02-28-2012, 08:39 AM
Administrator

doorfx's Avatar
ArcticChat.com Admin

Administrator
Join Date: Jan 2011
Location: calgary ab
Posts: 28,736
Thanks: 2,913
Thanked 2,666 Times in 2,451 Posts
Garage
ATV: 07 500 auto 13 700 XT trv
2010 Mileage: 800
2007 Mileage: 800
2006 Mileage: 800
Sounds like clutch rollers to me

Dynojet/142m/45p/3rd/3turns--Clipped and drilled--Unifilter--Easy adjust PMS--L.C.V. mod--AC Swaybar--Exhaust mod--2"Snorkels--Sanny shock bushings-- Airdam stage 1--PSC phase 2--21/ 23gr rollers--Dalton yellow spring--.7mm shim--Sanny Steerlites--RTR Flex Bracket--2 up seat / pegs--Tach--AC handguards--28" Outlaw mst's--Skull tailight--Skull shifter--Self Resetting Breakers--1" Wheel spacers--Customcncparts Steering Damper--AC deluxe handwarmers--6000k HID'S hi/lo--AC Deluxe Bumpers--Inline Fuel Filter-- O2 sensor \AFR guage--Black Magic Full Stainless Exhaust System--Wireless Winch Remote--29.5 Outlaws--Fox Podium X Rear Shocks--
2013 700 XT trv eps stock



It's mind over matter,If you don't mind,
It just doesn't matter

No Boost No Bottle
just balls and throttle
doorfx is offline
post #6 of 12 Old 02-28-2012, 03:27 PM Thread Starter
Member

Member
Join Date: Apr 2011
Location: ohio
Posts: 37
Thanks: 3
Thanked 0 Times in 0 Posts
Garage
well they said the rollers are fine now there checking the oil pump feels like they are just throwing things in the air and hope that something works on my dime(but it might just me) I thought by taking it to the dealer they would be able to figure it out but they have had it since last tuesday and still dont know what is wrong
dstarr20308 is offline
post #7 of 12 Old 02-28-2012, 03:43 PM
Member

RalphMotorsports's Avatar

Member
Join Date: Feb 2012
Location: Calgary
Posts: 33
Thanks: 0
Thanked 5 Times in 5 Posts
Timing chain is often the problem on your unit- it wears just out of reach of the tensioner and sometimes makes noise. To change the chain- you do have to remove all the way past the wet clutch- which means more gaskets also they have to clean and re-seal the rocker cover and double check and possibly adjust valves. Also if you have a worn out chain- I would think they are changing the oil too. By my rough estimate you would be at about 300 in parts and its a solid 3hrs- to do it properly. And depending if they are charging the diagnosis time with it and shop supplies and ect. It sounds like they are fairly close on your quote- maybe slightly high just to cover themself from the terrible under quote.
Just my opinion
RalphMotorsports is offline
post #8 of 12 Old 02-28-2012, 03:44 PM
Member

RalphMotorsports's Avatar

Member
Join Date: Feb 2012
Location: Calgary
Posts: 33
Thanks: 0
Thanked 5 Times in 5 Posts
I quick check on chain wear/noise is to remove the tensioner and keep pressure on the chain with a screwdriver or something and see if noise goes away!
RalphMotorsports is offline
post #9 of 12 Old 02-28-2012, 03:57 PM
Administrator

doorfx's Avatar
ArcticChat.com Admin

Administrator
Join Date: Jan 2011
Location: calgary ab
Posts: 28,736
Thanks: 2,913
Thanked 2,666 Times in 2,451 Posts
Garage
ATV: 07 500 auto 13 700 XT trv
2010 Mileage: 800
2007 Mileage: 800
2006 Mileage: 800
Quote:
Originally Posted by RalphMotorsports View Post
Timing chain is often the problem on your unit- it wears just out of reach of the tensioner and sometimes makes noise. To change the chain- you do have to remove all the way past the wet clutch- which means more gaskets also they have to clean and re-seal the rocker cover and double check and possibly adjust valves. Also if you have a worn out chain- I would think they are changing the oil too. By my rough estimate you would be at about 300 in parts and its a solid 3hrs- to do it properly. And depending if they are charging the diagnosis time with it and shop supplies and ect. It sounds like they are fairly close on your quote- maybe slightly high just to cover themself from the terrible under quote.
Just my opinion
The shop rates down in the state are almost half of what they are here. So if your at $120 and they are at $65 they would be high , right??

Dynojet/142m/45p/3rd/3turns--Clipped and drilled--Unifilter--Easy adjust PMS--L.C.V. mod--AC Swaybar--Exhaust mod--2"Snorkels--Sanny shock bushings-- Airdam stage 1--PSC phase 2--21/ 23gr rollers--Dalton yellow spring--.7mm shim--Sanny Steerlites--RTR Flex Bracket--2 up seat / pegs--Tach--AC handguards--28" Outlaw mst's--Skull tailight--Skull shifter--Self Resetting Breakers--1" Wheel spacers--Customcncparts Steering Damper--AC deluxe handwarmers--6000k HID'S hi/lo--AC Deluxe Bumpers--Inline Fuel Filter-- O2 sensor \AFR guage--Black Magic Full Stainless Exhaust System--Wireless Winch Remote--29.5 Outlaws--Fox Podium X Rear Shocks--
2013 700 XT trv eps stock



It's mind over matter,If you don't mind,
It just doesn't matter

No Boost No Bottle
just balls and throttle
doorfx is offline
post #10 of 12 Old 02-28-2012, 04:36 PM Thread Starter
Member

Member
Join Date: Apr 2011
Location: ohio
Posts: 37
Thanks: 3
Thanked 0 Times in 0 Posts
Garage
thanks guys well hope they figure it out soon
